Vintage polysynth · Mac app and plugins

A polysynth inspired by the 80s.

Oh-a-Synth is a 6-voice polysynth inspired by the classic sounds of the 80s. It's a standalone Mac app and an AU and VST3 plugin for your DAW, coming soon.

Tell me when it ships

Why I built this

I love the polysynths of the 80s. They're still all over records because they do a few things perfectly: rock-solid oscillators against a warm filter, and a chorus that turns one voice into a wall. So I built one that chases the feel, down to the small differences between voices that make six voices sound like six voices.

DCO

One oscillator per voice, read from band-limited wavetables so nothing aliases: a saw, a pulse with manual or LFO-swept width, a square sub one octave down, and a noise source shared across all voices, as on the hardware.

That era's character is solid pitch against a moving filter. Tuning never drifts here; the voice-to-voice tolerances live in the filter and amp instead, where the real chips had them.

The DCO section of the Oh-a-Synth panel with PWM SRC switched to LFO, above an oscilloscope showing the pulse wave the engine is playing, its width moving.

VCF + HPF

A 24 dB/oct zero-delay-feedback ladder filter that self-oscillates near the top of the RES range and tracks the keyboard via KYBD. In front of it sits the 4-position HPF. Position 0 is the famous low-shelf bass boost.

Sweep FREQ on a held chord and there is no zipper, no stair-stepping: slider moves are smoothed per-sample inside the audio thread.

The HPF and VCF sections with RES pushed high, above the filter's response: a resonant peak at the cutoff, FREQ 5.9, RES 8.3.

CHORUS

Two latching buttons, I and II; press both for I+II. A BBD-style stereo chorus modeled on the MN3009 bucket brigades: one delay line, two taps modulated in antiphase, wet path band-limited to 9 kHz.

This is the effect the era is remembered for. I is slow and lush, II runs faster, and I+II is the quick shallow warble the LESLIE ORGAN patch is built on.

The CHORUS section with buttons I and II both lit, above a stereo goniometer showing the chorus spreading one chord across left and right.

ARPEGGIO

UP, UP&DN, or DOWN across 1, 2, or 3 octaves. Free-running from 0.5 to 20 Hz, or hit SYNC and the RATE slider snaps to twelve note divisions from 1/1 to 1/64, dotted values included. HOLD latches the chord.

Synced, it locks to your DAW's playhead in the plugin and to MIDI beat clock everywhere else, realigned every beat so it cannot drift.

The ARPEGGIO section with ON, HOLD and SYNC lit, UP&DN and a two-octave range, synced at 1/16 and 128 BPM, above the keys the arpeggiator is playing.

PATCHES

Fifteen factory patches: nine sounds from FAT BASS to WARM PAD, and six drums built from the synth's own filter and noise. Save and name your own, and export or import them as flat .ohasynth.json files. In the app and plugin, favourite a patch ♥ and it gets its own section at the top of the selector.

The same file loads in the Mac app and the plugin. A patch you build in the app opens in Logic unchanged.

The whole Oh-a-Synth panel with BRASS 1 just picked from the patch menu, above the factory patches with BRASS 1 lit.

MIDI

Notes with velocity, pitch bend with separate DCO and VCF depths, mod-wheel vibrato, sustain pedal, and 24-ppqn beat clock for the arp. The status readout names what's connected and what isn't.

Those machines ignored velocity entirely. The VEL slider maps it gently to level; set it to zero for that behavior.

The BENDER pushed to the right, with its DCO and VCF depth sliders, above a chord held on the keyboard.

Hear it in a track

Sixty seconds of dark synthwave where every sound is Oh-a-Synth, drums included. Each part is its own instance of the synth, starting from a factory patch.

The drums are factory patches you can play: KICK DRUM is the VCF, self-oscillating, pinged by the envelope; SNARE DRUM and the hats are noise through the HPF.

Get it

Mac app and plugins

The standalone Mac app and the AU and VST3 plugins, in one bundle. Every parameter is automatable, and your patches load in all three. Downloads open once Apple's signing and notarization are done.

Tell me when it ships. One email to Nate, one reply when it's live.

Specifications

Polyphony6 voices, with voice stealing (releasing voices stolen first)
Oscillator1 DCO per voice: band-limited wavetable saw + pulse (manual/LFO PWM), square sub −1 octave, shared noise; 16′/8′/4′ range
Filter24 dB/oct zero-delay-feedback ladder, self-oscillating; env (±, up to 9 oct), LFO (±3 oct), key follow to 105%
High-pass4-position HPF; position 0 is a low-shelf bass boost
Envelope1 ADSR shared by VCF and VCA, RC-style exponential segments; VCA env or gate mode
LFOTriangle, 0.1–30 Hz, 0–2.5 s delay with fade-in, LFO TRIG override; routes to pitch, PWM, VCF
EffectsBBD-style stereo chorus: I (0.513 Hz), II (0.863 Hz), I+II (9.75 Hz)
ArpeggiatorUP / UP&DN / DOWN, 1–3 octaves, HOLD; free 0.5–20 Hz or synced (12 divisions, 1/1–1/64 incl. dotted); tempo from DAW transport (plugin), MIDI clock, or BPM 40–300
Plugin & appAU, VST3, and standalone. macOS 11+, universal binary (Apple Silicon + Intel). All parameters host-automatable, state saved with the project
MIDINotes with velocity, 14-bit pitch bend, mod wheel (CC1), sustain (CC64), all-notes-off (CC120/123), 24-ppqn beat clock
Patches15 factory (9 sounds, 6 drums) + unlimited user patches; flat .ohasynth.json, interchangeable between the app and the plugin
PriceNot announced
PriceNot announced

Questions

Will it work in my DAW?

On macOS, yes: AU for Logic, VST3 for everything else. Every panel parameter is host-automatable, the current patch saves with your project, and you can run as many instances as you like.

What about Windows?

Not yet. Oh-a-Synth is macOS only for now. If a Windows build happens, the notify list hears about it first.

Why can't I download it yet?

The app and plugins build and run today, but shipping them properly requires Apple Developer ID signing and notarization, which is in progress. The notify list gets the download link the day it's live.

Does it respond to velocity?

By choice. The machines this draws on ignored velocity entirely; here the VEL slider maps velocity gently onto level. Set it to zero for the period-correct response.

Do patches move between the app and the plugin?

Yes. A patch is a flat .ohasynth.json file that loads in both. Anything a patch doesn't name falls back to its default, so older patches keep loading as parameters are added.
